Broadband Single-Mode ASE Source

(540 to 2000nm)
  • High Stability
  • Low Cost
  • Ease to Use



This series of ASE (Amplified Spontaneous Emission) light sources are single mode light source with a broad emission spectrum and relatively low-coherent.  Our unit feature precision feedback control to provide high stability for accuracy measurement applications. The device is based on rare-earth-doped fibers with a pumping laser that is cooled for longevity.  With the wide availability of doped fibers, we offer fiber optical light source with a wide range of wavelengths; including 540 nm, 850 nm, 1300 nm, 1480 nm, 1550nm, 1610nm, 1900nm, 2000nm, and 2400nm. They are the ideal light sources for FBG sensors, OCT, fiber optic gyroscopes, gas sensors, and fluorescence excitation, as well as for measurement of optical components.  We produce both modular for system integration and  stand-alone bench-top for ease in uses.


There are no reviews yet.

Be the first to review “Broadband Single-Mode ASE Source”

Your email address will not be published. Required fields are marked *

ASE Light Source Min              Typical     Max Unit
Center Wavelength  540, 850,1060, 1030,1550 1600, 1950,2000,2400 nm
Bandwidth +-20 nm
Output Power 5 10 100 mW
Polarization Dependence 0.01 dB
Polarization Extinction (PM) 18 20 25 dB
Output Power Stability 0.05 0.1 0.2 dB
Output Isolation 10 dB
Input Voltage (AC) 110 110 220 V
Computer Interface USB
Power Consumption 20      W
Bias Voltage Range -15 15 V
Operating Temperature -5 60 oC
Storage Temperature -45 85 oC
